Grundfos 59896124
GRUNDFOS UP15-18BUC7 BRNZ 3/4
SKU
308606
Grundfos Circulator Pump, Canned Rotor, Series: UP Series, 7.71 gpm, 14.44 ft Maximum Head, 60 W, 115 VAC, 0.55 A, 60 Hz, 1 ph, 145 psi Maximum, Composite PES Impeller, 140 deg F, Radial/Thrust Bearing, 5-1/4 in W x 7-3/4 in H
- Ceramic shaft, radial bearings and carbon thrust bearing
- Stainless steel rotor can and bearing plate
- Impeller of corrosion-resistant material
- No additional motor protection is required
- Non-electronically controlled circulator pumps for domestic building with speed control
- Removable check valve
- Union connection
- Bronze pump housing
- Small stator
- Single speed motor
| Voltage Rating | 115 VAC |
|---|---|
| Power Rating | 60 W |
| Bearing Type | Radial/Thrust |
| Maximum Pressure | 145 psi |
| Maximum Head | 14.44 ft |
| Type | Canned Rotor |
| Amperage Rating | 0.55 A |
| Phase | 1 ph |
| Temperature Rating | 140 deg F |
| Dimensions | 5-1/4 in W x 7-3/4 in H |
| Series | UP Series |
| Impeller Type | Composite PES |
| Flow Rate | 7.71 gpm |
| Frequency Rating | 60 Hz |
| Brand | Grundfos |
