HAYWARD TB1400SE
4" HAYWARD TRUE UNION PVC BV
SKU
320610
HAYWARD® True Union Ball Valve, Series: TB Series, 4 in Nominal, Socket End Style, 235 psi Pressure, 34 to 140 deg F, Full Port, T-Handle Actuator, PVC Ball, 12.30 in Inlet to Outlet Length, 7.62 in Top to Inlet Center, PVC Body, PTFE Seat Trim, EPDM Softgoods
- All true union ball valves are assembled with silicone free lubricant and have PTFE seats
- For actuator-ready
- EPDM O-ring
| Ball Material | PVC |
|---|---|
| Port Type | Full |
| Actuator Type | T-Handle |
| Inlet to Outlet Length | 12.30 in |
| Body Material | PVC |
| Top to Inlet Center | 7.62 in |
| Trim Material | PTFE Seat |
| Series | TB Series |
| Softgoods Material | EPDM |
| Temperature Rating | 34 to 140 deg F |
| Pressure Rating | 235 psi |
| End Style | Socket |
| Nominal Size | 4 in |
| Brand | Hayward |
| Size | 4" |
| Type | Valves |
