Littelfuse KLLU1000
100A 600V TIME-DELAY FUSE
SKU
805053
Littelfuse® POWR-GARD® Time Delay Fuse, Current Limiting, Series: KLLU, Non-Indicating, 1000 A, 600 VAC/300 VDC, 20/200 kA Interrupt, Class: L, Knife Blade Terminal, Bolt Mounting, Cartridge Body, Melamine, 2-1/2 in Dia x 10-3/4 in L Body
- Current limiting - reduces short circuit damage to systems and equipment and reduced downtime
- Easily coordinated with other system components
- Ten second minimum time delay at 500 percent of rating eliminates needless downtime caused by heavy starting currents of large motors and other inductive loads
- Selective coordination - KLLU fuses coordinate well with other class L fuses and with all current-limiting Littelfuse® fuses rated 600 A or less
- Reduced downtime
- KLLU fuse time-current characteristics closely match typical time-current curves of circuit breakers
- Although fuse/circuit breaker systems can seldom be 100 percent coordinated , KLLU series fuses permit use of a wider range of breaker setting than fast-acting class L fuses
- Excellent protection for a single breaker or a group of breakers
- 200 kA at 600 VAC, 20 kA at 300 VDC interrupting rating
| Class | L |
|---|---|
| Body Size | 2-1/2 in Dia x 10-3/4 in L |
| Material | Melamine |
| Series | KLLU |
| Voltage Rating | 600 VAC/300 VDC |
| Indicating/Non-Indicating | Non-Indicating |
| Mounting Type | Bolt |
| Terminal Type | Knife Blade |
| Type | Current Limiting |
| Body Type | Cartridge |
| Amperage Rating | 1000 A |
| Interrupt Rating | 20/200 kA |
| Brand | Littelfuse Inc |
| Class | Class L |
