Grundfos 81595095
GRUNDFOS 5S05-9/1/2HP/230V/1PH
SKU
533139
Grundfos, 81595095, Submersible Pump, Series: SP Series, 4.81 gpm Flow Rate, 2 Wires, 9 Stage, 1/2 hp Power, 230 VAC, 6 A, 60 Hz Frequency, 1 ph, 3450 rpm Motor, 1.6 Service Factor, (9) 304 Stainless Steel Impeller, 68 deg F, IP68 Enclosure, Thrust Bearing, Stainless Steel, 3.98 in Dia x 24.57 in H Dimensions
- State-of-the-art hydraulics provide high efficiency and low operating costs
- 100% stainless steel components inside and outside for long service life
- Single phase motor with sand shield, liquid lubricated bearings and pressure equalizing diaphragm
- Resistant to aggressive water
- Dry running protection
- Monitoring, protection and communication via protection unit MP 204/Grundfos GO
- The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers
- 4 in Dia motor
- 1 in NPT pump outlet
- AISI 304 stainless steel parts
| Dimensions | 3.98 in Dia x 24.57 in H |
|---|---|
| Impeller Type | (9) 304 Stainless Steel |
| Power Rating | 1/2 hp |
| Flow Rate | 4.81 gpm |
| Power Rating | 1/2 hp |
| Amperage Rating | 6 A |
| Temperature Rating | 68 deg F |
| Voltage Rating | 230 VAC |
| Voltage Rating | 230 VAC |
| Series | 5S05-9 |
| Frequency Rating | 60 Hz |
| Series | SP Series |
| Number of Wires | 2 |
| Phase | 1 ph |
| Material | Stainless Steel |
| Number of Stages | 9 |
| Motor Speed | 3450 rpm |
| Material | Stainless Steel |
| Impeller Type | (9) 304 Stainless Steel |
| Bearing Type | Thrust |
| Enclosure Type | IP68 |
| Service Factor | 1.6 |
| Motor Speed | 3450 rpm |
| Phase | 1 ph |
| Enclosure Type | IP68 |
| Frequency Rating | 60 Hz |
| Temperature Rating | 68 deg F |
| Flow Rate | 4.81 gpm |
| Brand | Grundfos |
