Schneider Electric QO342MQ200
200A 3PH 42CKT MAIN BRKR LC
SKU
630619
Square D™ QO™ Main Breaker Load Center, 3-ph Convertible, 208Y/120 VAC, 240/120 Delta VAC, 240 Delta VAC, 200 A, 1 Pole, 50/60 Hz, 25 kA Interrupt, 42 Circuits, MB/QO Breaker, Panel Breaker Mounting, 4-Wire Wiring Configuration, 42 Spaces, 4 AWG to 300 kcmil Wire, Bolt-On Mount, NEMA 1, Sheet Steel Housing, 14.25 in W x 3.75 in D x 39.37 in H
- Tin plated aluminum bus construction on main lug or main circuit breaker panels
- Service entrance equipment capable panels
- Straight in wiring to help minimize service cable installations
- Single captive screw interior mounting on indoor panels to ease removal
- New side hinge doors on outdoor convertible main panels
- Outdoor panel covers are lockable with padlock
- Gray baked enamel electrodeposited over cleaned, phosphatized steel
- Top or bottom feed by rotating enclosure
- Does not accepts plug-on neutral circuit breaker
- Lug electrical connection
- 208Y/120 VAC, 120/240 VAC delta, 240 VAC delta
- Aluminum/copper wire
| Wire Size | 4 AWG to 300 kcmil |
|---|---|
| Type | 3-ph Convertible |
| Wiring Configuration | 4-Wire |
| Frequency Rating | 50/60 Hz |
| Enclosure Type | NEMA 1 |
| Number of Circuits | 42 |
| Number of Poles | 1 |
| Breaker Type | MB/QO |
| Mounting Type | Bolt-On |
| Dimensions | 14.25 in W x 3.75 in D x 39.37 in H |
| Interrupt Rating | 25 kA |
| Amperage Rating | 200 A |
| Housing Material | Sheet Steel |
| Breaker Mounting | Panel |
| Voltage Rating | 208Y/120 VAC, 240/120 Delta VAC, 240 Delta VAC |
| Number of Spaces | 42 |
| Brand | Square D Co |
