LEGEND 301-123NL
3/4X1/2 FNPT X SWT DIELEC UNIO
SKU
826942
LEGEND Dielectric Union, Lead Free, Series: T-571NL, 3/4 x 1/2 in Nominal, FNPT x C, 1.86 in Length, 200 psi, Forged Carbon Steel, Galvanized, 180 deg F, 1.63 in W, Import
- All fittings are UL listed and FM approved for fire suppression
- Manufactured using the latest technologies for material consistency and dimensional tolerances
- Designed to reduce stray current and galvanic corrosion where two dissimilar metals are joined
- Classified as a Class 150 malleable iron fitting, (rated at 150 psi) they are test pressure rated by UL and factory Mutual at 300 and 500 psi, configuration-specific
- Forged carbon steel, galvanized body, forged carbon steel, galvanized union nut lead free forged brass solder adapters, EPDM rubber gasket, ABS resin insert insulator
| End Style | FNPT x C |
|---|---|
| Pressure Rating | 200 psi |
| Dimensions | 1.63 in W |
| Length | 1.86 in |
| Finish | Galvanized |
| Temperature Rating | 180 deg F |
| Nominal Size | 3/4 x 1/2 in |
| Series | T-571NL |
| Domestic/Import | Import |
| Material | Forged Carbon Steel |
| Brand | Legend |
| Type | Dielectric Unions |
