EATON C25DNF240B
2 POLE 240V DEF.PUP.CONT.
SKU
676284
EATON Definite Purpose Control Contactor, D-Frame Non-Reversing, 208 to 240 VAC at 50/60 Hz Coil, 40 A Inductive/50 A Resistive Maximum Load Current, 2 Pole, Double Break Contact, Quick-Connect (Side by Side) Connection, Box Lug Terminal, Open Enclosure, 150 deg F Operating, Surface Mounting, 3.35 in L x 2.4 in W x 3.75 in H Dimensions
- The universal mounting plate eliminates changing hole patterns when replacing competitive devices
- Variety of terminal styles allows product to meet all specific application needs
- Snap-on accessories require no tools for hassle-free installation
- Quick coil changing ability allows for easy maintenance
- Non-position sensitive mounting allows for fast, convenient setup
- Shrouded or fingerproof terminals to reduce possibility of electrical shock
- 15 to 50 A frame
| Coil Voltage | 208 to 240 VAC at 50/60 Hz |
|---|---|
| Operating Temperature | 150 deg F |
| Mounting Type | Surface |
| Type | D-Frame Non-Reversing |
| Contact Type | Double Break |
| Connection Type | Quick-Connect (Side by Side) |
| Dimensions | 3.35 in L x 2.4 in W x 3.75 in H |
| Terminal Type | Box Lug |
| Number of Poles | 2 |
| Enclosure Type | Open |
| Maximum Load Current | 40 A Inductive/50 A Resistive |
| Brand | Eaton |
