HAYWARD TB2300SE
3" CPVC S/80 EPDM BALL VLV
SKU
331528
HAYWARD® True Union Ball Valve, Series: TB Series, 3 in Nominal, Socket, 235 psi, 34 to 180 deg F, Full Port, T-Handle Actuator, CPVC Ball, 10.56 in Inlet to Outlet Length, 6.46 in Top to Inlet Center, CPVC Body, PTFE Seat Trim, EPDM
- All true union ball valves are assembled with silicone free lubricant and have PTFE seats
- For actuator-ready
- EPDM O-ring
| End Style | Socket |
|---|---|
| Body Material | CPVC |
| Pressure Rating | 235 psi |
| Inlet to Outlet Length | 10.56 in |
| Softgoods Material | EPDM |
| Ball Material | CPVC |
| Top to Inlet Center | 6.46 in |
| Series | TB Series |
| Trim Material | PTFE Seat |
| Temperature Rating | 34 to 180 deg F |
| Actuator Type | T-Handle |
| Port Type | Full |
| Nominal Size | 3 in |
| Brand | Hayward |
| Size | 3" |
| Type | Valves |
