Siemens UA3717-YPRG
200A 4J METER SOCKET
SKU
708689
Siemens TALON® Multi-Position Meter Socket, Type UAS8/9 3-Position, 600 VAC, 200 A, 1 ph, Overhead/Underground Feed, 4 Jaws, 1/0 AWG to 600 kcmil, 6 AWG to 350 kcmil Wire, HD Opening Hub, 4.281 in Hub, Ringless Cover, Line/Load Lug Terminal, Insulated Insulation, Surface Mounting, NEMA 3R Enclosure, 6 in H x 15 in W x 33 in D Dimensions
- Glass filled polyester block construction
- Lay-in line side lug
- Steel construction
| Hub Type | HD Opening |
|---|---|
| Terminal Type | Line/Load Lug |
| Feed Type | Overhead/Underground |
| Mounting Type | Surface |
| Insulation | Insulated |
| Type | Type UAS8/9 3-Position |
| Phase | 1 |
| Enclosure Type | NEMA 3R |
| Dimensions | 6 in H x 15 in W x 33 in D |
| Hub Size | 4.281 in |
| Wire Size | 1/0 AWG to 600 kcmil, 6 AWG to 350 kcmil |
| Voltage Rating | 600 VAC |
| Number of Jaws | 4 |
| Amperage Rating | 200 A |
| Cover Type | Ringless |
| Brand | Siemens Ind |
